Product Overview
A Fixed Concrete Mixing Plant is a high-performance, stationary facility engineered for long-term, large-scale construction projects. Unlike mobile units, this plant is permanently installed at a designated site to serve as a reliable central hub for continuous concrete supply.
Designed for maximum stability and high-efficiency output, it is the ideal solution for demanding infrastructure projects and sites with sustained, high-volume concrete requirements.
ALQ Series Asphalt Mixing Plant Parameters
Technical specifications for ALQ40, ALQ60, ALQ80, ALQ100, ALQ120, and ALQ160 models.
| Model |
ALQ40 |
ALQ60 |
ALQ80 |
ALQ100 |
ALQ120 |
ALQ160 |
| Output |
40 t/h |
60 t/h |
80 t/h |
100 t/h |
120 t/h |
160 t/h |
| Batcher Capacity |
4×4.5 m³ |
4×6.5 m³ |
4×7.5 m³ |
4×7.5 m³ |
4×7.5 m³ |
5×12 m³ |
| Dryer Capacity |
60 t/h |
80 t/h |
100 t/h |
120 t/h |
140 t/h |
160 t/h |
| Vibrating Screen |
4 Layers |
| Asphalt Weigh Hopper |
100 kg |
120 kg |
150 kg |
150 kg |
250 kg |
250 kg |
| Mixer Capacity |
500 kg |
800 kg |
1000 kg |
1250 kg |
1500 kg |
2000 kg |
| Cycle Time |
45 Seconds |
| Screening Area |
230 m² |
300 m² |
420 m² |
480 m² |
550 m² |
650 m² |
| Asphalt Temperature |
140-180°C |
| Total Power |
170 kW |
200 kW |
300 kW |
350 kW |
380 kW |
490 kW |
ALQ Series Asphalt Mixing Plant — Comprehensive Technical Specifications
